In this post I'll talk about SAE 8617. First let's describe it and then have a look at its material's properties.

What is SAE 8617?

SAE 8617 is a nickel-chromium-molybdenum steel with 0.17% carbon, approximately.

Application

They are used in seamless mechanical tubing.

UNS Number

G86170

Ok let's start with SAE 8617 Chemical Composition.

Chemical Composition

C, Carbon

0.15–0.20

Mn, Manganese

0.70–0.90

P, Phosphorus max.

0.040

S, Sulfur max.

0.040

Si, Silicon

0.15–0.35

Ni, Nickel

0.40–0.70

Cr, Chromium

0.40–0.60

Mo, Molybdenum

0.15–0.25

Learn more about Chemical Composition.

Now it's the mechanical properties turn:

Yield Strength

320 MPa

Learn more about Yield Strength.

Tensile Strength

470 MPa

Learn more about Tensile Strength.

Elongation (min.)

0,25.

Learn more about Elongation.

Hardness

Brinell

140

Learn more about Hardness.

Density

7.8 g/cm3.

Learn more about Density.

Elastic Modulus

190 GPa.

Learn more about Elastic Modulus.

Poisson's ratio

0.29.

Learn more about Poisson's ratio.

Allowable Stress or Factor of Safety

Depends on the project (And its factor of safety).

Learn more about Allowable Stress or Factor of Safety.

My Material's Ranking Research

While engineers will often look for the cheapest material they can use, I took a different approach to material's selection to help newbie students.

I ranked materials according to their yield strengths and SAE 8617 currently ranks 118 in my yield strength index. This means there are other 117 materials that are more resistant.

Note: I've analysed 162 materials in order to create an yield strength index. Check my material's comparison post for more details.

SAE Classroom

Are you having trouble understanding the basics of SAE?

What is SAE: Classification and specification?

This video will walk you through:

References

ASTM A519 and other references.

Citation

When you need to include a fact or piece of information in an assignment or essay you should also include where and how you found that piece of information.

That gives credibility to your paper and it is sometimes required in higher education.

To make your life (and citation) easier just copy and paste the information below into your assignment or essay:

Luz, Gelson. SAE 8617 Properties (Chem., Mech. & Rankings). Materials Blog. Gelsonluz.com. dd mmmm. yyyy. URL

Now replace dd, mmmm and yyyy with the day, month, and year you browsed this page. Also replace URL for the actual url of this page. This citation format is based on MLA.

Equivalent Specifications

AMS 6272 ASTM A752 AFNOR 22 NCD 2 B.S. 805 H 20⁣
ASTM A29 ASTM A829 DIN 1.6523 B.S. 805 M 20⁣
ASTM A322 SAE J1397 UNI 20 NiCrMo 2 AMS 6272E⁣
ASTM A331 SAE J404 JIS SNCM 21 ASTM A505⁣
ASTM A519 AFNOR 20 NCD 2 JIS SNCM 21 H SAE J770⁣
