ASTM A453 Properties (Chem., Mech. & Rankings)

In this post I'll talk about and give details about ASTM A453. First let's describe it and then have a look at its material's properties.

What is ASTM A453?

ASTM A453 is a Specification for High-Temperature Bolting, With Expansion Coefficients Comparable to Austenitic Stainless Steels.

Category

Steel Bolting Materials

Scope

This specification covers five grades of bolting with twelve classes of yield strength ranging from 50 to 120 ksi (345 to 827 MPa) for use in high-temperature service such as fasteners for pressure vessel and valve flanges.

Ok let's start with ASTM A453 chemical composition.

Chemical Composition

Grade 660

C max.

0.08

Mn max.

2.00

P max.

0.040

S max.

0.030

Si max.

1.00

Ni

24.0 - 27.0

Cr

13.5 - 16.0

Mo

1.00 - 1.50

Ti

1.90 - 2.35

Al max.

0.35

V

0.10 - 0.50

B

0.001 - 0.010

Learn more about chemical composition.

Now it's the mechanical properties turn:

Yield Strength

Grade 660

85 ksi (585 MPa) min.

Learn more about what is yield strength.

Tensile Strength

Grade 660

130 ksi (895 MPa) min.

Learn more about what is tensile strength.

Elongation (min.) 4D

0.15.

Learn more about what is elongation.

Reduction of Area (min. %)

0.18.

Learn more about reduction of area.

Hardness Requirements

Grade 660

248 - 341 HB

Learn more about what is hardness.

Density

7480 - 8000 kg/m3 (around 7.9 g/cm3 or 0.285 lb/in3).

Learn more about density.

Elastic Modulus

180 GPa (26107 ksi) - 210GPa (30458 ksi).

Learn more about the Elastic Modulus.

Poisson's Ratio

Usually around 0.26 – 0.31.

Learn more about the poisson ratio.

Allowable Stress

Depends on the project (And its factor of safety).

Learn more about the what is allowable stress.

My Material's Rank

While engineers will often look for the cheapest material they can use, I took a different approach to material's selection to help newbie students.

I ranked materials according to their yield strengths and ASTM A453 currently ranks 16 in my yield strength index. This means there are other 15 materials that are more resistant.

Note: I've analysed 134 materials in order to create an yield strength index. Check my astm material's comparison post for more details.

ASTM Classroom

Are you having trouble understanding the basics of ASTM?

What is the difference between Code, Standard & Specification?

This video will walk you through:

References

Citation

When you need to include a fact or piece of information in an assignment or essay you should also include where and how you found that piece of information.

That gives credibility to your paper and it is sometimes required in higher education.

To make your life (and citation) easier just copy & paste the information below into your assignment or essay:

Luz, Gelson. ASTM A453 Properties (Chem., Mech. & Rankings). Materials Blog. Gelsonluz.com. dd mmmm. yyyy. <URL>

Now replace dd, mmmm and yyyy with the day, month, and year you browsed this page. Also replace URL for the actual url of this page (The < and > stay, ok?). This citation format is based on MLA.

Other References

A193/A193M Specification for Alloy-Steel and Stainless⁣
Steel Bolting for High Temperature or High Pressure⁣
Service and Other Special Purpose Applications⁣
A962/A962M Specification for Common Requirements for⁣
Bolting Intended for Use at Any Temperature from Cryogenic⁣
to the Creep Range⁣
E139 Test Methods for Conducting Creep, Creep-Rupture,⁣
and Stress-Rupture Tests of Metallic Materials⁣
