What is ASTM A209?
ASTM A209 is a Specification for Seamless Carbon-Molybdenum Alloy-Steel Boiler and Superheater Tubes.Category
Steel TubesScope
This specification covers several grades of minimum wall- thickness, seamless, carbon-molybdenum alloy-steel, boiler and super heater tubes.Ok let's start with ASTM A209 chemical composition.
Chemical Composition
Grade T1
C
0.10 - 0.20Mn
0.30 - 0.80P max.
0.025S max.
0.025Si
0.10 - 0.50Mo
0.44 - 0.65Learn more about chemical composition.
Now it's the mechanical properties turn:
Yield Strength
Grade T1
30 ksi (205 MPa) minLearn more about what is yield strength.
Tensile Strength
Grade T1
55 ksi (380 MPa) minLearn more about what is tensile strength.
Elongation (min.) 50 mm
0.3.Learn more about what is elongation.
Reduction of Area (min. %)
Not Required.Learn more about reduction of area.
Hardness Requirements
Grade T1
146 HBWLearn more about what is hardness.
Density
7800 - 8000 kg/m3 (around 7.9 g/cm3 or 0.285 lb/in3).Learn more about density.
Elastic Modulus
190 GPa (27557 ksi) - 210GPa (30458 ksi).Learn more about the Elastic Modulus.
Poisson's Ratio
0.27 – 0.30.Learn more about the poisson ratio.
Allowable Stress
Depends on the project (And its factor of safety).Learn more about the what is allowable stress.
My Material's Rank
While engineers will often look for the cheapest material they can use, I took a different approach to material's selection to help newbie students.I ranked materials according to their yield strengths and ASTM A209 currently ranks 106 in my yield strength index. This means there are other 105 materials that are more resistant.
Note: I've analysed 134 materials in order to create an yield strength index. Check my astm material's comparison post for more details.
Details and PDF
Instructions:
- Go to this page.
- Type the name of the standard you are looking for in the search box. Tip: Don't forget to include "ASTM" as a keyword.
- Read the details about the standard or download the PDF.
ASTM Classroom
Are you having trouble understanding the basics of ASTM?What is the difference between Code, Standard & Specification?
This video will walk you through:
References
Citation
When you need to include a fact or piece of information in an assignment or essay you should also include where and how you found that piece of information.That gives credibility to your paper and it is sometimes required in higher education.
To make your life (and citation) easier just copy & paste the information below into your assignment or essay:
Luz, Gelson. ASTM A209 Properties (Chem., Mech. & Rankings). Materials Blog. Gelsonluz.com. dd mmmm. yyyy. <URL>
Now replace dd, mmmm and yyyy with the day, month, and year you browsed this page. Also replace URL for the actual url of this page (The < and > stay, ok?). This citation format is based on MLA.
Other References
A1016/A1016M Specification for General Requirements forFerritic Alloy Steel, Austenitic Alloy Steel, and Stainless
