ASTM A192 Properties⚙️ (Chem., Mech. & Rankings) rev. 2022

What is ASTM A192?

ASTM A192 is a Specification for Seamless Carbon Steel Boiler Tubes for High-Pressure Service.

Category

Steel Tubes

Scope

This specification covers minimum-wall thickness, seamless carbon steel boiler and super heater tubes for high pressure service.

Ok let's start with ASTM A192 chemical composition.

Chemical Composition

C

0.06 - 0.18

Mn

0.27 - 0.63

P max.

0.035

S max.

0.035

Si max.

0.25

Learn more about chemical composition.

Now it's the mechanical properties turn:

Yield Strength

26 ksi (180 MPa) non mandatory

Learn more about what is yield strength.

Tensile Strength

47 ksi (325 MPa) non mandatory

Learn more about what is tensile strength.

Elongation (min.) 50 mm

35% non mandatory.

Learn more about what is elongation.

Reduction of Area (min. %)

Not Required.

Learn more about reduction of area.

Hardness Requirements

137 HB or 77 HRB min

Learn more about what is hardness.

Density

7800 - 8000 kg/m3 (around 7.9 g/cm3 or 0.285 lb/in3).

Learn more about density.

Elastic Modulus

190 GPa (27557 ksi) - 210GPa (30458 ksi).

Learn more about the Elastic Modulus.

Poisson's Ratio

0.27 – 0.30.

Learn more about the poisson ratio.

Allowable Stress

Depends on the project (And its factor of safety).

Learn more about the what is allowable stress.

My Material's Rank

While engineers will often look for the cheapest material they can use, I took a different approach to material's selection to help newbie students.

I ranked materials according to their yield strengths and ASTM A192 currently ranks 130 in my yield strength index. This means there are other 129 materials that are more resistant.

Note: I've analysed 134 materials in order to create an yield strength index. Check my astm material's comparison post for more details.

Details and PDF

Instructions:

  1. Go to this page.
  2. Type the name of the standard you are looking for in the search box. Tip: Don't forget to include "ASTM" as a keyword.
  3. Read the details about the standard or download the PDF.

ASTM Classroom

Are you having trouble understanding the basics of ASTM?

What is the difference between Code, Standard & Specification?

This video will walk you through:

References

Citation

When you need to include a fact or piece of information in an assignment or essay you should also include where and how you found that piece of information.

That gives credibility to your paper and it is sometimes required in higher education.

To make your life (and citation) easier just copy & paste the information below into your assignment or essay:

Luz, Gelson. ASTM A192 Properties (Chem., Mech. & Rankings). Materials Blog. Gelsonluz.com. dd mmmm. yyyy. <URL>

Now replace dd, mmmm and yyyy with the day, month, and year you browsed this page. Also replace URL for the actual url of this page (The < and > stay, ok?). This citation format is based on MLA.

Other References

A 450/A 450M Specification for General Requirements⁣
for Carbon, Ferritic Alloy, and Austenitic Alloy Steel⁣
Tubes⁣
A 520 Specification for Supplementary Requirements for⁣
Seamless and Electric-Resistance-Welded Carbon Steel⁣
