ASTM A135 Properties (Chem., Mech. & Rankings) 2022

In this post I'll talk about and give details about ASTM A135. First let's describe it and then have a look at its material's properties.

What is ASTM A135?

ASTM A135 is a Specification for Electric-Resistance-Welded Steel Pipe.

Category

Steel Pipe

Scope

This specification covers two grades of electric resistance- welded steel pipe in NPS 2 to NPS 30 inclusive, with nominal (average) wall thickness up to 0.500 in. (12.70 mm), inclusive, and in nominal sizes NPS 3/4 to NPS 5 inclusive with nominal (average) wall thickness 0.083 in. (2.11 mm) to 0.134 in. (3.40 mm).

Ok let's start with ASTM A135 chemical composition.

Chemical Composition

Grade A

C max.

0.25

Mn max.

0.95

P max.

0.035

S max.

0.035

Learn more aboutĀ chemical composition.

Now it's the mechanical properties turn:

Yield Strength

Grade A

30 ksi (207 MPa) min

Learn more aboutĀ what is yield strength.

Tensile Strength

Grade A

48 ksi (331 MPa) min

Learn more aboutĀ what is tensile strength.

Elongation (min.) 50 mm

0.35.

Learn more aboutĀ what is elongation.

Reduction of Area (min. %)

Not Required.

Learn more aboutĀ reduction of area.

Density

7800 - 8000 kg/m3 (around 7.9 g/cm3 or 0.285 lb/in3).

Learn more aboutĀ density.

Elastic Modulus

190 GPa (27557 ksi) - 210GPa (30458 ksi).

Learn more about theĀ Elastic Modulus.

Poisson's Ratio

0.27 ā€“ 0.30.

Learn more about theĀ poisson ratio.

Allowable Stress

Depends on the project (And its factor of safety).

Learn more about theĀ what is allowable stress.

My Material's Rank

While engineers will often look for the cheapest material they can use, I took a different approach to material's selection to help newbie students.

I ranked materials according to their yield strengths and ASTM A135 currently ranks 100Ā in my yield strength index. This means there are other 99 materials that are more resistant.

Note: I've analysed 134 materials in order to create an yield strength index. Check my astm material's comparison post for more details.

Details and PDF

Instructions:

  1. Go to this page.
  2. Type the name of the standard you are looking for in the search box. Tip: Don't forget to include "ASTM" as a keyword.
  3. Read the details about the standard or download the PDF.

ASTM Classroom

Are you having trouble understanding the basics of ASTM?

What is the difference between Code, Standard & Specification?

This video will walk you through:

References

Citation

When you need to include a fact or piece of information in an assignment or essay you should also include where and how you found that piece of information.

That gives credibility to your paper and it is sometimes required in higher education.

To make your life (and citation) easier just copy & paste the information below into your assignment or essay:

Luz, Gelson. ASTM A135 Properties (Chem., Mech. & Rankings). Materials Blog. Gelsonluz.com. dd mmmm. yyyy. <URL>

Now replace dd, mmmm and yyyy with the day, month, and year you browsed this page. Also replace URL for the actual url of this page (The < and > stay, ok?). This citation format is based on MLA.

Other References

A 370 Test Methods and Definitions for Mechanical Testingā£
of Steel Productsā£
A 700 Practices for Packaging, Marking, and Loadingā£
Methods for Steel Products for Domestic Shipmentā£
A 751 Test Methods, Practices, and Terminology forā£
Chemical Analysis of Steel Productsā£
A 865 Specification for Threaded Couplings, Steel, Blackā£
and Zinc-Coated (Galvanized) Welded or Seamless, forā£
Use in Steel Pipe Jointsā£
A 941 Terminology Relating to Steel, Stainless Steel,ā£
Related Alloys, and Ferroalloysā£
E 6 Terminology Relating to Methods of Mechanicalā£
Testingā£
E 29 Practice for Using Significant Digits in Test Data toā£
Determine Conformance with Specificationsā£
E 59 Practice for Sampling Steel and Iron for Determinationā£
of Chemical Compositionā£
E 213 Practice for Ultrasonic Examination of Metal Pipeā£
and Tubingā£
E 273 Practice for Ultrasonic Examination of Longitudinalā£
Welded Pipe and Tubingā£
E 309 Practice for Eddy-Current Examination of Steelā£
Tubular Products Using Magnetic Saturationā£
